Why ROS 2 for Embedded Systems?

ROS 2 (Robot Operating System 2) is the successor to ROS 1, rebuilt from the ground up with embedded and safety-critical deployment in mind. Its key improvements — a DDS-based communications layer, real-time executor support, no dependency on a central ROS master process, and first-class support for ARM architectures — make it viable for deployment directly on embedded Linux targets rather than being confined to developer workstations.

Choosing the Right ROS 2 Distribution

ROS 2 distributions follow Ubuntu LTS cycles. For embedded deployments, prefer an LTS distribution with long-term support: Humble Hawksbill (supported through 2027) is the current recommendation. Its Tier 1 platform support includes Ubuntu 22.04 on ARM64, which aligns with Raspberry Pi OS 64-bit and Jetson's Ubuntu-based JetPack.

Installation on Raspberry Pi 4/5

# On Raspberry Pi OS (64-bit, Bookworm)
sudo apt install software-properties-common
sudo add-apt-repository universe
sudo curl -sSL https://raw.githubusercontent.com/ros/rosdistro/master/ros.key   -o /usr/share/keyrings/ros-archive-keyring.gpg
echo "deb [arch=arm64 signed-by=/usr/share/keyrings/ros-archive-keyring.gpg]   http://packages.ros.org/ros2/ubuntu jammy main"   | sudo tee /etc/apt/sources.list.d/ros2.list
sudo apt update
sudo apt install ros-humble-ros-base python3-colcon-common-extensions

The ros-base metapackage installs the core DDS transport, rclpy/rclcpp, and command-line tools without desktop GUI tools — appropriate for headless embedded targets.

Your First ROS 2 Node

import rclpy
from rclpy.node import Node
from sensor_msgs.msg import Temperature

class TemperatureSensor(Node):
    def __init__(self):
        super().__init__("temperature_sensor")
        self.publisher = self.create_publisher(Temperature, "sensor/temperature", 10)
        self.timer = self.create_timer(1.0, self.publish_reading)
        self.get_logger().info("Temperature sensor node started")

    def publish_reading(self):
        msg = Temperature()
        msg.header.stamp = self.get_clock().now().to_msg()
        msg.temperature = self.read_sensor()  # Your hardware read call
        msg.variance = 0.1
        self.publisher.publish(msg)

def main():
    rclpy.init()
    node = TemperatureSensor()
    rclpy.spin(node)
    node.destroy_node()
    rclpy.shutdown()

DDS Tuning for Resource-Constrained Targets

ROS 2's default DDS middleware (eProsima Fast DDS) is configured for a local network with multiple machines. On a single-board embedded target, tune it for minimal overhead:

export FASTRTPS_DEFAULT_PROFILES_FILE=/opt/ros/humble/share/fastrtps/examples/cpp/dds/HelloWorldExample/MIN_FOOTPRINT_PROFILE.xml
export RMW_FASTRTPS_USE_QOS_FROM_XML=1

Consider switching to CycloneDDS (ros-humble-rmw-cyclonedds-cpp) for lower memory footprint on embedded targets. CycloneDDS consistently uses 30-40% less memory than Fast DDS in single-node configurations.

Real-Time Nodes with the StaticSingleThreadedExecutor

For nodes with timing requirements, use the StaticSingleThreadedExecutor to avoid dynamic allocation during spin and combine with a real-time Linux thread:

#include "rclcpp/rclcpp.hpp"
#include <pthread.h>
#include <sched.h>

int main(int argc, char * argv[]) {
    rclcpp::init(argc, argv);
    auto node = std::make_shared<MotorControlNode>();
    rclcpp::executors::StaticSingleThreadedExecutor exec;
    exec.add_node(node);

    // Elevate thread priority
    struct sched_param param = {.sched_priority = 80};
    pthread_setschedparam(pthread_self(), SCHED_FIFO, &param);

    exec.spin();
    rclcpp::shutdown();
}

Cross-Compilation for ARM Targets

Build ROS 2 packages on a development machine and deploy binaries to the target to avoid the slow build times on single-board computers. Use QEMU user-mode emulation with a sysroot that matches your target:

colcon build   --cmake-args     -DCMAKE_TOOLCHAIN_FILE=arm64_toolchain.cmake     -DCMAKE_SYSROOT=/opt/sysroots/aarch64-rpi4

Conclusion

ROS 2 on embedded Linux is production-viable when you select the right DDS implementation, tune the middleware for your hardware, and use the appropriate executor for your timing requirements. The investment in a proper cross-compilation setup pays for itself immediately — compile on a fast development machine, deploy to the target, and iterate rapidly.
